Product Description
|
Model
|
P61G
|
|
Size
|
202*72.5*32mm
|
|
Weight
|
Host with battery: 370g (Net weight) 738g (including UHF, including handle battery)
|
|
Button
|
Main keyboard (optional): 27 keys/37 keys/47 keys;
Side keys: 2 scan keys + 2 volume keys + 1 custom key |
|
Battery
|
6700 mAh detachable battery for main unit, 5200 mAh detachable battery for optional handle, support QC3.0 fast charge and RTC,
built-in 100mAh backup battery, support battery hot swap, improve system reliability and effectively ensure user data security |
|
Standby time up to 680 hours (with only the host battery installed, up to 560 hours in WIFI mode and 560 hours in 4G mode)
|
|
|
Working hours > 12 hours (depending on usage and network environment)
|
|
|
Speaker
|
support
|
|
Vibration
|
support
|
|
Mic
|
Two, one for noise cancellation, back
|
|
Screen
|
4-inch HD full screen, IPS LTPS 800 X 480
|
|
Touch screen
|
Support multi-touch, support glove or wet hand operation
|
|
Sensor
|
Gravity sensor, distance sensor, light sensor, acceleration sensor, vibration motor
|
|
Indicator light
|
Power, charging, status lights
|
|
Card slot
|
1 Micro SIM card slot, 1 TF card slot
|
|
Communication Interface
|
Android 9: Type-C, OTG
Android 11:Type-C, OTG |
|
CPU
|
Android 9：QCOM Snapdragon™450 8-core, 1.8 GHz
Android 11：QCOM Snapdragon™662 8-core, 2.0 GHz |
|
RAM+ROM
|
3GB+32GB / 4GB+64GB / (6GB+128GB, 500 units minimum order)
|
|
Expand memory
|
MicroSD (TF) card expandable up to 128GB
|
|
operating system
|
Android 9 / 11
|
|
SDK
|
Exclusive terminal software development kit
|
|
Development language
|
Java
|
|
development tools
|
Eclipse / Android Studio
|
|
Working temperature
|
‘-20 ℃ to +50 ℃
|
|
Storage temperature
|
’-40 ℃ to +70 ℃
|
|
Ambient temperature
|
5% RH~95% RH (non-condensing)
|
|
Drop height
|
Within the operating temperature range, all 6 sides can withstand multiple (at least 20) drops from a height of 1.8 meters to a
concrete floor |
|
Rolling test
|
Rolling continuously for 1000 times of 0.5 meters, the 6-surface contact surface still runs stably after rolling, reaching the IEC
rolling specification |
|
Protection LEVEL
|
IP65, meets IEC sealing standards
|
|
Static Protection
|
±15 KV air discharge, ±8 KV contact discharge
|
|
WIFI
|
2.4G/5G dual-band, support 802.11 a/b/g/n/ac/d/e/h/i/k/r/v, IPV4, IPV6, 5G PA
|
|
Fast roaming: PMKID caching, 802.11r, OKC;
|
|
|
Working channel (depending on local regulations): 2.4G (channel 1~13), 5G (channel 36, 40, 44, 48, 52, 56, 60, 64, 100, 104, 108,
112, 116, 120, 124, 128, 132, 136, 140, 144, 149, 153, 157, 161, 165); |
|
|
Security encryption: WEP, WPA/WPA2-PSK (TKIP and AES), WAPI_x005f_x0002_PSK—EAP-TTLS, EAP-TLS, PEAP-MSCHAPv2, PEAP LTS, PEAP-GTC,
etc.; |
|
|
4G
|
2G: 850/900/1800/1900MHz
|
|
3G: CDMA EVDO: BC0
|
|
|
WCDMA：850/900/1900/2100MHz
|
|
|
TD-SCDMA：A/F（B34/B39）
|
|
|
4G: B1/B3/ B5/B7/B8/B20/B38/B39/B40/B41
|
|
|
Vo-LTE
|
Support Vo-LTE HD video and voice calls
|
|
BT
|
Android 9: Support BT 4.2/4.1+HS/4.0/3.0+HS/2.1+EDR
Android 11: BT 5.1 |
|
GNSS
|
Integrated GPS, Beidou, GLONASS and Galileo, support AGPS, built-in antenna
|
|
Camera
|
Rear 13 million color camera, support auto focus, flash
|
|
NFC
|
Operating frequency: 13.56 MHZ
Protocol standard: ISO14443A/B, ISO15693, NFC-IP1, NFC-IP2, etc. Label standard: M1 card (S50, S70), CPU card, NFC tag, etc. Read and write distance: 2-4 cm |
|
RFID
|
Optional
|
|
Scanner
|
Optional
|
Product Videos
Custom Field
Barcode Scanner : Yes
